Machine Weight: 20,680 lbs
Max Payload: 14,300 lbs
Engine: Mitsubishi 6D16TLI
Horsepower @ 2,200 RPM: 224 hp
Fuel Capacity: 52 Gallons
Top Speed: 7.5 MPH
Ground Pressure (Empty): 2.40 psi
Ground Pressure (Loaded): 4.10 psi
Gradeability: 30°
Side Stability: 50°
Ground Clearance: 19.5"
Length: 20’5”
Width: 8’6”
Height: 10’5”
Weight: 22,000 lbs.
-
Max Lifting Capacity: 6,000 lbs.
Boom Length: 10’7”
Max Horizontal Reach: 20’8”
Max Vertical Reach: 22’
Max. Winch Line Pull Speed: 60 ft/min
Boom Elevation: -5° to +80°
Crane Rating: 380,00 ft-lbs.
