Machine Weight 22,708 lbs
Max Payload 14,300 lbs
Engine Isuzu 6HK1DH1
Horsepower @ 2,200 RPM 228 hp
Fuel Capacity 53 Gallons
Top Speed 7.2 MPH
Ground Pressure (Machine Only) 3.50 psi
Ground Pressure (Full) 5.7 psi
Ground Clearance 19"
Length 17’9”
Width 8’6”
Height 9’3”
-
Max Lifting Capacity: 6,000 lbs.
Boom Length: 10’7”
Max Horizontal Reach: 20’8”
Max Vertical Reach: 22’
Max. Winch Line Pull Speed: 60 ft/min
Boom Elevation: -5° to +80°
Crane Rating: 380,00 ft-lbs.
