Weight: 27,500 lbs.
Capacity: 25,000 lbs.
Ground Pressure (Empty): 2.94 psi
Ground Pressure (Loaded): 5.91 psi
Engine: Caterpillar C7.1 ACERT
Horsepower @ 2,200 RPM: 250 HP
Torque @ 1,400 RPM: 895.4 lb-ft
Max Speed: 6.2 mph
Fuel Tank Capacity: 65 gallons
Tracks: 29.5"
Length: 19’3”
Width: 8’5”
Height: 9’11”
Ground Clearance: 21”
Uphill/Downhill Gradeability: 60%
Side Hill Gradeability: 40%
-
-JOST’s signature 3-point locking system features three locks with just four moving parts to ensure ultimate safety & simplicity
-Infinite lock adjustment reduces unnecessary wear and ensures that the play between the fifth wheel and the king pin is perfectly adjusted
-A replaceable cushion ring reduces the lifetime cost of ownership.
-Innovative anti-high coupling lugs prevent drivers from high coupling by either guiding the kingpin into the jaws or pushing it up and over
-Features a maximum horizontal rating of 150,000 lbs.
