Weight: 27,500 lbs.
Capacity: 25,000 lbs.
Ground Pressure (Empty): 2.94 psi
Ground Pressure (Loaded): 5.91 psi
Engine: Caterpillar C7.1 ACERT
Horsepower @ 2,200 RPM: 250 HP
Torque @ 1,400 RPM: 895.4 lb-ft
Max Speed: 6.2 mph
Fuel Tank Capacity: 65 gallons
Tracks: 29.5"
Length: 25’3”
Width: 8’5”
Height (Railings Down): 10’
Height (Railings Up): 11’5”
Ground Clearance: 21”
Uphill/Downhill Gradeability: 60%
Side Hill Gradeability: 40%
-
Model: Bowie 1650
Discharge Distance: 200+ feet
Tank Capacity: 1,700 gallons
-Integrated Shredder System for faster loading
-Triple Agitators for faster mixing and more homogenous slurry
-Reversible Agitation and Pump operation
-4” Bowie Gear – Our biggest Gear Pump, capable of spraying any type off mulch material regardless of slurry thickness and without cavitation issues.
Lower Maintenance Costs – The Bowie 1650 has no engine, being powered entirely from the crawler. This drastically reduces routine maintenance and repair issues for the Hydro-Mulcher.
Greater Stability – The lower profile of the Bowie 1650 increases operator safety on the most uneven terrain. The elimination of the engine also allows the unit to maintain a better center of gravity, increasing the overall stability of the unit.
Lower Transport Profile – The lower profile and collapsible rails make transport of the unit easier and with less disassembly. The T12 is also 8’5” wide, making it legal shipping width and reducing transportation cost.
Greener Machine – The elimination of the engine on the Hydro-Mulcher reduces potential emissions and provides for a more environmentally friendly unit.
