Weight: 32,673 lbs.
Capacity: 25,000 lbs.
Ground Pressure (Empty): 3.50 psi
Ground Pressure (Loaded): 6.20 psi
Engine: Caterpillar C7.1 ACERT
Horsepower @ 2,200 RPM: 275 HP
Torque @ 1,400 RPM: 927 lb-ft
Max Speed: 8.4 mph
Fuel Tank Capacity: 65 gallons
Length: 20’
Width: 8’5”
Height: 9’11”
Track Height: 29.4"
Ground Clearance: 21”
Uphill/Downhill Gradeability: 60% (31°)
Sidehill Gradeability: 40% (21.8°)
-
Dump Box Capacity (Struck): 6.4 yd3
Dump Box Capacity (Heaped): 7.7 yd3
Dump Body Length: 143”
Box Width: 89”
Inner Box Width: 83”
Inner Box Height (Sides): 28”
Headboard Height: 54”
Dump Box Peak Height: 198”
