Machine Weight: 40,558 lbs.
Payload: 33,500 lbs.
Maximum Speed: 8 mph
Ground Pressure (Empty): 3.71 psi
Ground Pressure (Loaded): 6.87 psi
Engine: Caterpillar C7.1 Acert
Horsepower @ 2200 rpm: 275 hp
Torque @ 1400 rpm: 927 lb-ft
Fuel Tank Capacity: 86 Gallons
Uphill Gradeability: 31°
Side Hill Gradeability: 21.8°
Length: 26’2”
Width: 9’9”
Height: 10’
Ground Clearance 20"
-
Dump Box Capacity (Struck): 8.6 yd3
Dump Box Capacity (Heaped): 11.5 yd3
Dump Body Length: 177”
Box Width: 102”
Inner Box Width: 96”
Inner Box Height (Sides): 28”
Headboard Height: 57”
Dump Box Peak Height: 248"
