The Prinoth Panther T8 is an extremely versatile rubber tracked crawler carrier with a truck inspired chassis. With very low ground pressure, loaded and unloaded, these machines are designed to go nearly anywhere without much effort. Their 34-inch-wide chassis allows them to be outfitted with a number of different implements, making them an ideal platform for many applications. This crawler carrier is outfitted with a Western FuelCube FCP1000. This fuel tank is perfect for onsite fueling, with a 1,000-gallon diesel fuel tank capacity and a 100-gallon DEF tank. A lockable equipment cabinet on the fuel tank ensures that equipment and fuel ports are kept secure as well as catching any spills. It also has double walled construction, ensuring that the tank is leak proof and increasing stability when the tank is full. For more information about purchasing or renting this machine, do not hesitate to call Multi Machine Inc.
Machine Specifications
Hours: 2181
Serial #: 935200626
Machine Weight: 25,000 lbs.
Machine Capacity: 16,000 lbs.
Engine: Caterpillar C7.1 Acert
Horsepower @ 2200 rpm: 225 hp
Torque @ 1400 rpm: 758 lb-ft
Max Speed: 6.2 mph
Fuel Tank Capacity: 65 Gallons
Ground Pressure (Empty): 2.22 psi
Ground Pressure (Loaded): 4.10 psi
Ground Clearance: 17”
Length: 18’5”
Width: 8'
Height: 8’11”
Fuel Cube Specifications
Model: Western FuelCube FCP1000
Serial Number: 19008316
Tank Capacity: 1,016 US GAL
Weight (Empty): 2,760 lbs
Weight (Full): 11,239 lbs
Fuel Cube Dimensions
Length: 91”
Width: 87”
Height: 47”
DEF Tank Specifications
Tank Capacity: 100 gallons
Pump Type: Vane
Fill Point: ¾”
Hose Length: 20’
Dry Weight: 105 lbs
Material: Polyethylene
Gun Type: Auto Shut-off
Electric Cable Length: 21”
Flow Rate: 8 gallons per minute
DEF Tank Dimensions
Length: 47”
Width: 34”
Height: 34”
