Machine Weight: 23,500 lbs.
Machine Capacity: 16,000 lbs.
Engine: Caterpillar C7.1 Acert
Horsepower @ 2200 rpm: 225 hp
Torque @ 1400 rpm: 758 lb-ft
Max Speed: 6.2 mph
Fuel Tank Capacity: 65 Gallons
Ground Pressure (Empty): 2.22 psi
Ground Pressure (Loaded): 4.10 psi
Ground Clearance: 17”
Length: 21’5”
Width: 8'
Height: 9’6”
Bed Rail Height: 52”
-
Hopper Height: 3’ 11”
Hopper Width: 6’ 2”
Hopper Length: 11’
Hopper Capacity: 168 cu. ft.
Overall Height: 7’ 2”
Overall Width: 7’ 2”
Overall Length: 18’ 4”
Suspension: Walking Beam
Wheel Track Width: 5’ 8”
Empty Weight: 4280 lb.
Maximum Gross Weight: 20,280 lb.
